Ten models have been developed in optimized compact modules, covering a power range of 7 to 40 kW.
Impressive Efficiency
Heating
Cooling
Low Noise Levels
Sustainability with Future Care
Compact Size
What are the MECH-iB-G07 and MEHP-iB-G07 Modular Chillers?
These are innovative systems from Mitsubishi Electric, suitable for residential buildings, commercial spaces, industrial, and IT applications. Both series use R32 refrigerant and are based on full inverter technology, ensuring maximum efficiency under varying operating conditions.
Училищата и университетите се нуждаят от енергийно ефективна и лесно управляема климатична система, за да се справят с прегряване от слънчево греене и да осигурят комфортна учебна среда.
Системата Hybrid VRF осигурява стабилен контрол на температурата в помещенията, без наличие на хладилен агент в обитаваните зони. Това значително улеснява съответствието със стандарта BS EN 378 и елиминира нуждата от скъпи системи за откриване на течове.
Премахването на хладилния агент от обитаваните пространства прави Hybrid VRF идеално решение за медицински обекти, като осигурява надежден температурен контрол и оптимален комфорт за пациенти и медицински екипи.
Благодарение на гъвкавия си дизайн, Hybrid VRF е идеална система за офис пространства. Децентрализираната архитектура позволява поетапен монтаж и лесна пренастройка при промени във вътрешното разпределение.
В сърцето на системата Hybrid VRF стои Hybrid Branch Controller (HBC). Всеки HBC може да бъде разширен с помощта на подчинени модули (Sub HBC), като поддържа до 50 вътрешни тела. Mitsubishi Electric предлага широка гама от вътрешни тела, в зависимост от изискванията в интериора на конкретния търговец.
Hybrid VRF е идеално решение за съвременни, плътно изолирани високи сгради, като съчетава комфорта на чилър с гъвкавостта и ефективността на VRF системи. Чрез използването на хладилен агент R32 с нисък GWP, собствениците и инвеститорите покриват своите ESG/CSR цели и гарантират устойчивостта на сградите си в дългосрочен план.
How does the system work?
MECH-iB-G07 Chillers
The new MECH-iB-G07 air-cooled chiller series is equipped with an inverter-driven scroll compressor. The system is compact and durable, and thanks to its extended operating range and specialized options, it is suitable for air conditioning and cooling of server rooms and data centers, industrial applications, residential, and small commercial spaces. It offers capacities from 15 to 40 kW.
Six models have been developed in optimized compact modules, covering a power range of 15 to 40 kW.
MEHP-iB-G07 Heat Pumps
The MEHP-iB-G07 heat pump from Mitsubishi Electric is specially designed for small to medium commercial applications, providing heating, cooling, and domestic hot water production throughout the year. The system is a fully equipped Plug-and-Play solution, thanks to the integrated hydraulic module with automatic flow regulation. It is an ideal solution for both renovations of existing buildings and sustainable new construction, suitable for commercial spaces, offices, and residential buildings. It offers capacities from 7 to 40 kW.
Advantages of MECH-iB-G07 and MEHP-iB-G07 Modular Chillers
Environmentally Friendly Refrigerant – R32 is a modern and more sustainable alternative to traditional R410A, offering 66% lower Global Warming Potential, higher efficiency, and reduced refrigerant charge.
Integrated Hydraulic Module – The integrated hydraulic module saves costs, time, and installation space by including all components of the water circuit.
Variable Flow Circulation Pumps – Energy savings through pump speed control according to required capacity. This also ensures stable operation even under critical conditions.
High Partial Load Efficiency, Thanks to Patented Technical Solutions – Inverter-driven scroll compressors, variable-speed fans, and brushless DC motors, combined with advanced control algorithms, ensure optimal efficiency.
MECH-iB-G07 Chillers
- Extended Operating Range – Reliable operation with chilled water outlet temperatures from -12 °C to +24 °C, and ambient temperatures from -20 °C to +50 °C, making the system suitable for year-round use, even under extreme climatic conditions.
- Extremely Compact Design – One of the best solutions in this class in terms of the ratio between occupied space and produced capacity.
Master-Client Function – Group control of up to 4 units is standard in MECH-iB-G07, providing maximum flexibility.
MEHP-iB-G07 Heat Pumps
- Extended Operating Range – Wide temperature range allows domestic hot water production up to 60 °C (for heating and hot water) and operation at ambient temperatures down to -20 °C.
- System Efficiency – The unit is designed as an integrated system: all components operate synergistically using patented algorithms to achieve maximum possible energy efficiency.
- Intelligent Defrosting – Advanced self-adjusting defrost technology considers all operating parameters and external conditions. The number and duration of defrost cycles are minimized, increasing efficiency and real heating capacity.
High-Tech Solutions Designed for Efficiency and Sustainability
Heat Pumps
MEHP-iB-G07
MEHP-iB-G07
Domestic Hot Water – Supports production up to 60 °C, managed via the integrated controller.
Reduced Energy Consumption
Dynamic control of the supply water temperature according to the outdoor temperature significantly improves comfort and the system’s energy efficiency.
Compressors
Mitsubishi Electric scroll compressors with inverter control. Sound-insulated and mounted on anti-vibration pads for quieter operation.
1. Heat Exchanger
The heat exchangers are made of copper tubes and aluminum fins, sized to ensure optimal performance under all operating conditions. A protective grille for the heat exchanger is standard for all sizes.
2. Construction
Self-supporting panels made of hot-dip galvanized steel, painted in RAL7035 with red and black accents. Durability and aesthetics combined.
3. EC Fans
Fans with EC motors and continuous speed control, which optimize airflow, ensure low energy consumption, and provide higher efficiency.
4. Refrigerant Circuit
The system uses an electronic expansion valve with an advanced DSH algorithm, specially designed for R32 refrigerant, for higher efficiency and reliability.
5. Variable Flow Circulation Pumps
Built-in pumps with EC motors and intelligent flow control logic (regulated according to system requirements).
6. Compressors
Mitsubishi Electric scroll compressors with inverter control. Sound-insulated and mounted on anti-vibration pads for quieter operation.
Advantages of MECH-iB-G07 and MEHP-iB-G07 Modular Chillers
Industrial Applications
Extended operating temperature range, including:
- Supply water temperature down to -12 °C
- Operation at outdoor temperatures down to -20 °C
The system uses highly reliable components and allows additional customization through available options such as:
- High head pumps
- Freeze protection
Data Centers
Extended Operating Range:
- Supply water temperature up to 24 °C
- Operation at outdoor temperatures up to 50 °C with ΔT up to 10 °C
Specialized Options and Accessories Include:
- High Head Pumps
- KIPlink Interface
- Energy Monitoring
Residential and Commercial Buildings
High Efficiency Values:
Up to EER = 3.4; SEER = 5.7, suitable for installation in residential buildings and commercial spaces.
Specialized Options Available:
- KIPlink Interface
- Energy Monitoring
- Master/Client Configuration
